Salient Features
- High Operating Efficiency And Low Power Bill
- Light weight & Noiseless operation
- Most Of The Models Have ISI Mark
- Wet Type, Water Cooled Rewindable Motors
- Withstand wide voltage fluctuations
Applications
- Fire Fighting, Bungalows & Apartments
- Flow / Drip / Sprinkler / Irrigation
- Private / Public Water Supply
- Small Discharge High Pressure Water Supply
Standard Material of Constructions (MOC)
| SR. NO | MOTOR PARTS | MATERIAL |
|---|---|---|
| 1 | Base Cover | CI - FG210 Grade |
| 2 | Bearing Bush | LTB-4 |
| 3 | Bearing Diaphragm | Carbon / Teflon |
| 4 | Housing | CI - FG210 Grade |
| 5 | Lamination | CRNGO / CRC |
| 6 | Rotor | Cooper / Alluminium |
| 7 | Rotor Shaft | S.S.410 |
| 8 | Stator Body / Casing | S.S.202 |
| 9 | Thrust Bearing Segment | S.S.304 |
| 10 | Winding Wire | Copper |
| SR. NO | PUMP PARTS | MATERIAL |
|---|---|---|
| 1 | Casing | CI - FG210 Grade |
| 2 | Hardware Parts | S.S.410 |
| 3 | Impeller | CI - FG210 Grade |
| 4 | NRV Body | CI - FG210 Grade |
| 5 | Pump Shaft | S.S.410 |
| 6 | Pump Sleeve | S.S.410 |
| 6 | Suction Casing | CI - FG210 Grade |
Standard Material of Constructions (MOC)
| SR. NO | MOTOR PARTS | MATERIAL |
|---|---|---|
| 1 | Base Cover | CI - FG210 Grade |
| 2 | Bearing Bush | LTB-4 |
| 3 | Bearing Diaphragm | Carbon / Teflon |
| 4 | Housing | CI - FG210 Grade |
| 5 | Lamination | CRNGO / CRC |
| 6 | Rotor | Copper |
| 7 | Rotor Shaft | S.S.410 |
| 8 | Stator Body / Casing | S.S.202 |
| 9 | Thrust Bearing Segment | S.S.304 |
| 10 | Winding Wire | Copper |
| SR. NO | PUMP PARTS | MATERIAL |
|---|---|---|
| 1 | Casing | CI - FG210 Grade |
| 2 | Hardware Parts | S.S.410 |
| 3 | Impeller | CI - FG210 Grade |
| 4 | NRV Body | CI - FG210 Grade |
| 5 | Pump Shaft | S.S.410 |
| 6 | Pump Sleeve | S.S.410 |
| 6 | Suction Casing | CI - FG210 Grade |
